Product Advantage
  • Water tube Steam boiler system

    On the basis of the existing water tube steam boiler structure, we optimized the arrangement of the water wall and the convection tube bundle, and changed the flow mode of high-temperature flue gas in the boiler. Changing from a direct flow to a vortex is conducive to the heat exchange of high-temperature flue gas and water. You only need less fuel to run the same capacity boiler system to save more fuel costs.

  • Coal-fired steam boiler combustion system

    We use the most advanced combustion system to provide a heat source for the system. Through the air duct, the rational layout of the grate is optimized, making the ratio of air and fuel more reasonable. It can promote the rapid and full combustion of the fuel, combined with the dust removal system to reduce the suspended dust, nitrogen oxides and sulfur oxides in the flue gas, your fuel will be fully utilized.

  • Fuel supply system for textile industry

    We provide the most suitable fuel delivery system for every EPCB boiler user, which can quickly refuel the boiler, ensure that the boiler has sufficient fuel supply and the steam generation rate is more stable. Simple, easy to operate, combined with the electric control system, can better complete the use and management of the boiler.

  • Textile industry control system.

    The water tube steam boiler control system will be programmed in accordance with the characteristics of the textile industry, and adjusted according to user habits and conditions, and continuously optimize the application process of the system to make the system more suitable for your food factory production, so as to achieve a more fuel-saving effect. You can save More fuel expenditures.

  • Steam boiler system for textile industry

    The steam boiler system will be customized design and production according to the different technology of the textile industry. Make the combustion process and steam supply more in line with the production needs of the food industry. Choose the best materials to ensure the stability and safety of the boiler body. You can therefore have a safe and stable boiler system suitable for your plant.

Technical Parameters

We will recommend your Steam Boiler for Textile Factory Water Tube Coal Fired boiler system model according to your actual needs. Of course we can provide you with comprehensive technical support。

Item/Type

Steam Boiler for Textile Factory Water Tube Coal Fired

Rated capacity t/h

4

6

8

10

12

15

20

25

Rated steam pressure MPa

1.25/1.6/2.5

Rated steam temperature ℃

194/204/226

Feed water temperature ℃

20

20

60

60

60

104

104

104

Thermal efficiency %

81.54

81.6

81.8

82.2

82.5

82.5

82.8

83.7

Heating surface m2

Boiler body

99.68

155.5

181.63

233.6

298

316.7

456

625.3

Economizer

69.76

140.6

183.1

209.3

209.3

225

242.4

267.8

Fuel & consumption

Fuel type

Class II Soft Coal, Biomass, Wood Chips, Wood Pellets,
 Rice Husk, Palm Kernel Shell, etc.

Coal kg/h

454.99

681.98

907.08

1128.34

1349.08

1686.35

2240.32

2770.29

Biomass kg/h

657.55

985.61

1310.93

1630.69

1949.71

2437.14

3237.74

4003.66

Size of boiler largest parts mm

Length

7500

6800

6900

7900

8100

9300

11500

11500

Width

2800

3200

3100

3400

3100

3300

3300

3300

Height

3500

3500

3500

3500

3500

3500

3500

3500

Weight of largest
parts of boiler ton

30

40

55

45/30

50/30

52/31

55/34

56/37



No.

Item

Example/Issuer

Qty

Unit

1

Boiler Drawings

General Drawing, Boiler Proper Drawing, PID (Pipes, Instruments & Valves) Drawing, Foundation Drawing, Boiler Room Design Drawing.

1

Set

2

Boiler Quality Certificate

Issued by the boiler inspection department of China government.

1

Set

3

Certificate of Origin

Such as CO, Form E, Form F, Form A, etc.

1

Set

4

Boiler Thermodynamic Calculation Book

Issued by the boiler supplier.

1

Set

5

Boiler Strength Calculation Book

Issued by the boiler supplier.

1

Set

6

Installation & Operation Instruction

Issued by the boiler supplier.

1

Set
